3D Navigation

Manipulating simulations in 3D requires navigating the 3D view in a comfortable way. The scene and all the contents have a fixed world reference frame (station reference) and the camera is moved to generate your desired point of view.

It is recommended to use a 3-button mouse to navigate in 3D. Alternatively, you can use a combination of Ctrl, Alt and Shift keys with a simple mouse left click perform Pan, Rotate or Zoom motions.

Select

Pan

Rotate

Zoom

Basic Guide - Image 8

Basic Guide - Image 9

Basic Guide - Image 10

Basic Guide - Image 11

Basic Guide - Image 12

Basic Guide - Image 13

Basic Guide - Image 14

Basic Guide - Image 15

Left click

Hold mid button

Hold right click

Move mouse wheel

Hold Ctrl to select more than
one object

Hold Ctrl + Alt
and
select

Hold Ctrl + Shift
and
select

Hold Shift
and
select



Basic Guide - Image 16

Right click on the main screen to see the same 3D navigation commands. This is useful if you are using a laptop and you don’t have access to a mouse.
